Technical specifications

Mechanical

• Device diameter 90 mm
• Device height34 mm

• Device weight (air)200 grams

• Device weight (submerged) 125 grams
• Depth rating1,000 meters

• Materials PEEK (housing)
• Stainless steel 316 (back plate)

• Operating temperature-5 to 60 °C


Electrical / Interface

• Input voltage10-30 Vdc

• Power consumption8 W (average)

• Power-on current surge30 W (maximum)

• Physical interface8 wires (pwr/serial/Ethernet)
• with interface module
• Side cable - 3 meter cable (PUR 6.7 mm diameter)
• Rear O-ring interface - 1 meter cable (PUR 6.7 mm diameter)

• Indicator Status LED (Power, Lock)

• Communication Ethernet, Serial (RS232)
• Protocols Water Linked API, PD0, PD4, PD6


Acoustic / Performance

• Transducer frequency625 kHz

• Transducer setup4-beam convex Janus array

• Transducer beam angle22.5 degrees

• Ping rate4-15 Hz (adaptive to altitude)

• Sensor assist Integrated AHRS/IMU

• Min altitude5 cm

• Max altitude100 meters
• (maximum altitude dependent on seabed conditions, salinity levels, etc.)

• Max velocity5 m/s

• Velocity resolution0.1 mm/s

• Long term accuracy±1.01 % (Standard version)
• ±0.1 % (Performance version)

Approvals

• CE certificate
  Yes
• RoHS compliant
