RS150 GPS RECEIVER

Specifications

• Nominal supply voltage 12V D.C. Powered by N2K bus
• Operating voltage range 8 - 32V DC
• Power consumption 30 mA max (NMEA LEN = 1)
• Operating temperature -13ºF to 131ºF (-25ºC to +55ºC)
• Relative humidity max 93%
• Waterproof IPx6/7
• Supported connection protocols SeaTalkng: NMEA 2000 (certified) (via DeviceNet adaptor)
• Sensitivity High sensitivity - acquisition down to -163dBm
• No. of channels 72
• Positioning System GPS & GLONASS
• Satellite Differential Type WAAS (United States); EGNOS (Europe); MSAS (Japan); GAGAN (India)
• Differential acquisition Automatic
• Position accuracy (95%) <15m
• Position accuracy with SDGPS (95%) <5m
• Speed accuracy (95%) <0.3kt
• Time to first fix from cold start <2 minutes (< 45 seconds typical)
• Time to first fix from hot start < 8 seconds -72 hour hold up battery allows for hot start
• Geodetic Datum WGS84
• Mounting Surface/rail/pole

In the Box

• GPS receiver unit
• Mounting seal
• SeaTalkng spur cable (3 metres)
• Documentation
• M4 x 40mm Threaded studs x 3 (used for surface mounting)
• Finger nuts x 3 (used for surface mounting)
