T200 Thruster with Penetrator (BlueROV2 Spare) - Counterclockwise
Blue Robotics

T200 Thruster with Penetrator (BlueROV2 Spare) - Counterclockwise

SKU: BR-102911-003
£239.99
inc. VAT
All Thrusters, Actuators and Lights Products
This T200 comes with a slightly shorter cable and a pre-installed cable penetrator and is a drop-in replacement for the thrusters on the BlueROV2. It’s also included in the BlueROV2 Spares Kit.
£239.99
inc. VAT

Product Description

This T200 comes with a slightly shorter cable and a pre-installed cable penetrator and is a drop-in replacement for the thrusters on the BlueROV2. It’s also included in the BlueROV2 Spares Kit.

Also, remember that this thruster needs an electronics speed controller (ESC), like the Basic ESC, to operate.

Technical Specifications

Specifications

ParameterValue
Performance
Full Throttle FWD/REV Thrust @ Nominal (16 V)5.25 / 4.1 kg f11.6 / 9.0 lb f
Full Throttle FWD/REV Thrust @ Maximum (20 V)6.7 / 5.05 kg f14.8 / 11.1 lb f
Minimum Thrust0.02 kg f*0.05 lb f*
Electrical
Operating Voltage7–20 volts
Full Throttle Current @ Nominal (16 V)24 Amps
Full Throttle Current @ Maximum (20 V)32 Amps
Full Throttle Power @ Nominal (16 V)390 Watts
Full Throttle Power @ Maximum (20 V)645 Watts
Physical
Length113 mm4.45 in
Diameter100 mm3.9 in
Wetted MaterialsPolycarbonate 10% glass-filled
Epoxy
Stainless steel
Plastic
Polyurethane
7075-T6 Aluminum
FKM
Buna-N
Weight in Air (with 1m cable)0.76 lb344 g
Weight in Water (with 1m cable)0.34 lb156 g
Propeller Diameter76 mm3.0 in
Mounting Hole Threads4x M3x0.5
1x M6x1.0
Mounting Hole Depth(M3) 6 mm
(M6) 8 mm
Mounting Hole Spacing (M3)19 mm0.75 in
Recommended Fastener Installation Torque0.5–1.3 N·m (M3 fasteners)
3–5 N·m (M6 fastener)

Cable
Cable UsedBR-100997
Cable Length*See drawing
Conductor Gauge16 AWG
Installed PenetratorM10-6.5mm-LC
