Shaft Length

Short (381mm) - Long (508mm)

Colour

Pearl Nebular Black

Steering Type

Tiller

Tilt

Manual

Starter

Manual

Weight

Short 24Kg - Long 25Kg

DIMENSIONS AND WEIGHTS

Recommended transom height

Short 381mm (15in) - Long 508mm (20in)

Weight:

Short 24kg - long 25Kg

Bore x Stroke:

60.4 x 48.0mm

Propeller Selection (pitch):

6" - 7"

ENGINE SPECIFICATION

Starting System:

Manual

Engine Type:

OHV

Fuel Delivery System:

Carburettor

No. of Cylinders:

1

Piston Displacement:

138cc

Maximum Output:

2.9kw

Full Throttle Operating Range:

4,000 - 5,000

Steering:

Tiller

Oil Pan Capacity:

0.7L

Fuel Tank Capacity:

Integral 1.0L

Ignition System:

Digital CDI

Engine Mounting:

Bushing Type

Trim Method:

Manual

Gear Ratio:

1.92:1

Gear Shift:

F-N-R

Exhaust:

Above Prop Exhaust
